Technical Parameter
-Electrical Specification and Connections
Power supply:
AC90--275V,50--60HZ
Power Consumption:
80W
Lens Angle:
25 degrees
Beam Angle:
15~20 degrees
DMX-Control-Channels:
10/13 DMX Channels
Pan:
Horizontal 540
Tilt:
Vertical 200
P/T Fine:
8-16bit
Prism:
3-Face Rotatable prism
Focusing:
Electronic linear focusing from near to far
Shuttle:
Flash rate:0--16HZ
Dissipate heat:
Air/convective heat transfer
Color wheel:
7 colors + blank
GOBO:
7 patterns+ blank,2 of which are glass patterns
Data input and output:
3-core XLR plug audio socket
LED 80W
Spot Moving Head
With 3 Prism
Miniaturized / Strong Material,Exquisite Structure / Temperature Control
High Brightness,Clear Projection / Sturdy Sockets / 3-Prism
Electronic Linear Focusing / Fast Delivery From Local Warehouses
(EU,US,RU)
![](http://shehds.com/cdn/shop/files/1_7e1df451-7870-401c-a182-49c2bde6bdbf_2048x2048.png?v=1709100229)
![](http://shehds.com/cdn/shop/files/2_d55a61ec-4882-4587-a6e4-2b61e1c26a42_2048x2048.png?v=1709100252)
Features And Scenarios
Manufacturing Atmosphere
Suitable for various scenarios
Bar / Concert / Party / Wedding
3-Prism / Sturdy Sockets / Miniaturized / Clear Projection /
Temperature Control / Technology
Size & Dimension
Vertical270°
Horizontal540°
Size:21x16.5x27cm
Weight:3.5kg
![](http://shehds.com/cdn/shop/files/5a22689bfb0dd0e587dbebc75365bac9_2048x2048.png?v=1719645796)
![](http://shehds.com/cdn/shop/files/4_b8bb3fc7-676a-4ef1-a120-21bdc186ac1e_2048x2048.png?v=1709100296)
Product Parts Introduction
Iron Caron Socket / PowerCon Socket, Fuse
Display Screen / Function Key / Up Or Down / Confirm Key
DMX IN / DMX OUT / Power Supply
3-Prism
![](http://shehds.com/cdn/shop/files/5_c7becc09-524a-4138-a27e-bbb1d8a13bef_2048x2048.png?v=1709100325)
![](http://shehds.com/cdn/shop/files/6_ee06a9e4-2c69-483b-b7cf-eaa7bf8b8f79_2048x2048.png?v=1709100342)
About Light
High Brightness Clear Projection
Electronic Linear Focusing 15°~20°
Convenient Transportation
Fast Delivery From Local
Warehouses (EU, US, RU)
Warehouses in multiple locations help you get your lamps earlier
![](http://shehds.com/cdn/shop/files/12_1c57e707-ab70-4cbf-9efe-35434e3613a3_2048x2048.png?v=1709100380)
Packing List
Each process undergoes strict verificationEvery part is carefully selected
![](http://shehds.com/cdn/shop/files/13_ee5c1df8-957b-443b-98b7-2adc097962a7_2048x2048.png?v=1709100526)
Flight Case
DIY Service
Equipped with silent 360 degree wheels + brake lockers
Note: This is DIY service,
please consult customer service for details!
