Technical Parameter
-Electrical Specification and Connections
Power supply:
AC90--275V,50--60Hz
Power:
350W
-Source
Light Source:
350W bulb
Dmx Channel:
16 CH
-Optical System
Scanning Angle:
X:540°，Y: 190°
Beam Angle:
0.2 degree parallel beam
Dimmer:
Mechanical Double Gate Dimmer
-Control and Programming
Control:
DMX512, RDM, master-slave, auto, sound control
Gobos:
13 gobos + white light (including 3 glass gobos)
Color Wheel:
14 colors + 1 white light
Prism:
8 prisms、8+16+24 prisms and forward and reverse rotation
Frost:
1 atomizing tablet
Ranbow:
6-color rainbow effect
-Mechanical Specification
Function:
RDM,intelligent temperature control, manual scene editing
Net Weight:
13.4 kg
Gross Weight:
15kg
Product Size:
52X25X31 cm
Package Size:
63x43x39 cm
Parallel beam light
350W 152mm large-caliber beam cannon
Speaking Vehicles With Four-Wheel Drive
Are Commonly Referred To As Cars
Applicable Scenes Lighting Can Be Used In A Variety Of Scenarios
Party / theater / Concer / Holtel / bar / weding
Production Features
GOBO / PRISM-ROT / PAN/TILT / Ranbow
3-pin DMX / 350W bulb / frost / FUCOS
Production Size
Product Size::52X25X31 cm
Net Weight:13.4 kg
Beam Angle
0.2° beam angle - linear focus
Brightness Lumen
Lux - DIstance
Function Introduction
DMX512 signal cable & power cable interface
Rainbow Beam
New Ｆrost Lens
Stage Effect
13 GOBOS & 14COLORS
6-color Rainbow Effect
Prism superposition and rotation
Strong beam effect
Infinitely changing combined beam
Scene Effect
Infinitely changing combined beam
Prism + Rainbow Disk Effect
It can flexibly shape the uniform and colorful pattern effect of the light spot, and easily show the wonderful phantom light effect.
Packing List
Each process undergoes strict verificationEvery part is carefully selected
Flight Case DIY Service
Equipped with silent 360 degree wheels + brake lockers
Note: This is DIY service,
please consult customer service for details!
