Technical Parameter
-Electrical Specification and Connections
Power supply:
180W Electronic auto-ranging
Input voltage range:
100-240 V, 50/60 Hz
Power in connector:
Neutrik powerCON
-Source
Light source type:
150W LED
Colour temperature output:
7500±500 K
10m/20m Beam Illuminance:
7790 lux @ 10m / 2500 lux @20m
Life expectancy:
min. 15000 hours
-Optical system
Beam angle:
Beam 2.8°- Frost 14°- Prism 12.5°
Dimmer:
0~100% linear dimming
Lens diameter:
120mm
-Dynamic Effects and Features
Colour wheel :
11 fixed dichroic colours + open
Static gobo wheel:
14 static gobos + open
Prism:
18-facet prism rotating in both directions at variable speed
Frosts:
Fast change frosts for instant softening of the projected gobo or framing shutters
Raimbow wheel:
6 colors
-Control and programming
Protocols:
DMX512
DMX channel mode：
15 CH;
Moving head range:
Pan:450° Tilt：210°
Feature：
Auto mode ,sound mode,Manual programming scenarios
-Mechanical specification
Housing :
High temperature resistant and flame retardant plastic housing
Product size：
24x18x41 cm / 9.45x7.09x16.14 inch
Product weight:
6.72 kg
Package size:
43x32x31 cm / 16.93x12.60x12.20 inch
Package weight:
8.08 kg
Operating temperature:
-20~60℃
Ingress protection rating:
IP20
180W BEAM MOVING HEAD LIGHT
The 180W beam not only has a fashionable and compact appearance,
but also perfectly integrates beam, dyeing,
and pattern effects The color temperature reaches up to 7500K,
and in beam mode, the illumination at 10 meters reaches 7790 lux, with a sharp sense.
The excellent light output creates a strong visual impact for the performance.
Product Features
Flexibly shaping uniform and colorful pattern effects, effortlessly showcasing exciting and colorful illusion lighting effects.
Uniform color mixing and excellent color reproduction can create a dazzling stage light and shadow visual experience,
Improve the level of stage performance in all aspects, providing high-quality choices
for various professional performance venues such as concerts, bars, evening parties, roadshows, etc.
Product Size
Product size:24x18x41 cm / 9.45x7.09x16.14 inch
Product Weights:6.72 kg
Lumen Value Display
In the lighting industry, lumens serve as a significant metric for assessing the brightness of light fixtures, reflecting the luminous efficacy and the overall quality of the lighting output. When selecting lighting fixtures, the lumen value aids us in understanding the illuminative strength that the particular fixture is capable of providing.
120mm Optical Coated Large Lens
More powerful and spectacular beam of light,
The pattern is clearer and more natural,New Process Technology for Colorful Coating
Beam Angle
Beam effect - 2.8 degrees ，Prism effect - 12.5 degrees
Frost effect - 14 degrees
The beam angle refers to the angle formed in a specific device, such as with sound waves, light waves, or electromagnetic waves, where during the transmission process of energy from the source, the energy intensity attenuates to half of its peak power (-3dB), defining the spread or concentration of the energy.
Effect Show
Colors Effect 14 Static Gobos +open / 11 Fixed Dichroic Colours + open
Prism Effect Display
Bright And Colorful
Frost Effect Display
Rendering the Stage Atmosphere
Beam Effect
Uniform and colorful pattern effects with uniform light spots
Packing List
Each process undergoes strict verificationEvery part is carefully selected
Flight Case
DIY Service
Equipped with silent 360 degree wheels + brake lockers
Note: This is DIY service,
please consult customer service for details!
