In some immersive small-scale theatre performances, when you need to highlight a character or a stage set, using a large ellipsoidal or a professional framing fixture is often too expensive and wasteful, while a standard PAR can is too scattered. In an art gallery, you want to place a beam precisely within the frame of a painting without spilling light onto the wall. In these situations, what you need is not a high-power wash light, but a precise, compact, and ultra-quiet professional ellipsoidal spotlight.
SHEHDS proudly introduces the all-new Mini LEKO 100W LED ellipsoidal spotlight which is available in cool white and warm white versions. It integrates manual zoom, a 4-leaf framing shutter system, high CRI, flicker-free operation, and many other professional features into one single unit. With DMX control, theatres, TV studios, exhibitions, and small stages can all enjoy clean, crisp shaping light from just one fixture.
1. More than just a front light – a shaping tool
Traditional stage spotlights are often bulky and limited in function: some can adjust beam size but cannot frame, while others can frame but lack zoom. Mini LEKO combines all these professional capabilities into a compact body. One light does it all – saving effort and trouble.
It integrates manual zoom, a 4-leaf framing shutter, high CRI (≥90), flicker-free dimming, DMX control, ultra-quiet operation, and supports both truss hanging and floor placement. Whether in a theatre, TV studio, or small stage, one Mini LEKO delivers professional, flexible, and quiet framing light.
Small venues no longer need a complex lighting rig – just one Mini LEKO can create professional stage depth and layers.
2. Key performance highlights
Mini LEKO breaks the stereotype that “professional stage spotlights must be heavy and bulky.”
The entire fixture weighs only 2.45 kg and features a compact size (396×148×143 mm), easily held in one hand.
Even though the size is reduced, performance is uncompromised – it retains full manual zoom, framing shutters, and DMX control, truly embodying “small body, pro soul.”
● Can be hung from a truss or placed flat on the ground
● Suitable for theatres, TV studios, exhibitions, churches, small stages
● Ideal for touring, rental, and temporary setups
● Space-saving design without sacrificing professional control.
| Parameter | Mini LEKO 100W |
|---|---|
| Total / LED Power | 103W / 100W LED |
| Fixture Weight | 2.45 kg (5.4 lbs) |
| Fixture Dimensions | 396×148×143 mm (15.6×5.8×5.6 in) |
| Beam Angle | 17° - 40° manually adjustable |
| Color Temperature Options | Cool white 6886K / Warm white 2751K |
| Color Rendering Index (CRI) | CRI ≥ 90 |
| Control Protocol | DMX512 |
| Channel Modes | 2CH / 6CH |
| Noise Level | Standby 33dB / On 45dB |
✅ How to choose the right version for you?
Cool white (6886K): Ideal for modern theatres, TV studios, and environments that require clean white light.
Warm white (2751K): Perfect for traditional stages, concerts, and scenes that need a warm skin tone atmosphere.
3. Precise imaging – clean, sharp beam edges
1. The heart of the Mini LEKO lies in the crispness of its beam edge. With high-transmittance optical lenses and a precision-engineered optical system, it delivers a beam with a razor-sharp edge and minimal spill light.
● Manual zoom from 17° to 40° (manual focus)
● At minimum angle, the beam is concentrated like a blade
● At maximum angle, it maintains even illumination and a clean edge
Whether you need spot tracking, local shaping, or cutting rectangular or square light patterns, the Mini LEKO delivers exactly where you aim – no stray light, no distortion.
2. Manual framing – freeform shaping
The Mini LEKO is equipped with a manual framing system (shutter blades). Four adjustable blades let you trim the light beam like cutting paper.
● Easily create rectangular, trapezoidal, or other custom shapes
● Precisely control where the light lands, avoiding spill on unintended areas
● Especially suited for art galleries, museums, product displays, and close-up accents
With the included gel frame holder, you can also use RGB color filters (free gift) or DIY GOBO patterns, turning a single spotlight into a versatile creative tool.
3. High CRI white light – true color rendition
Professional stage and theatre lighting demands excellent color fidelity.
The Mini LEKO is available in three light source versions: cool white (6886K), warm white (2751K), and a mixed option, all with CRI ≥90, ensuring:
● Pure, non-shifted color output
● True reproduction of skin tones and stage scenery
● Camera-friendly performance with flicker-free, 0-100% linear dimming
—— What you see is what you get, no post-production color correction needed.
4. Ultra-quiet operation for demanding environments
Many stages and studios have zero tolerance for noise. The Mini LEKO produces only 33 dB on standby and 45 dB when lit.
● Won’t interfere with live audio recording or performance atmosphere
● Die-cast aluminum body with efficient passive cooling
● Silent fan design eliminates wind noise
5. Professional control – plug and play
The Mini LEKO 100W supports DMX512 control with two channel modes (2CH and 6CH), compatible with most lighting consoles.
● Clearly laid out rear interface: power input / link-through, DMX input / output
● Supports auto-run mode for demonstration without a console
● Comes with a black 1-to-2 power splitter cable for daisy-chaining multiple units
Even for temporary small-stage setups, lighting and configuration can be completed quickly.
4. Overseas influencer reviews – real results speak for themselves
Lighting reviewers and professional lighting designers from Europe and the US have created unboxing and test videos for the Mini LEKO 100W. They have explored the product in depth across multiple dimensions:
1. Unboxing
Clear presentation of product appearance and accessories. Package includes: waterproof power cord x1, signal cable x2, gel frame holder x1, RGB color filter x1, GOBO holder x1, manual x1.
2. Mounting and operation demo
Step-by-step guide on quick installation and setup – easy even for a single operator.
3. Light output and function test
Full demonstration of actual light performance, including manual zoom, framing control, color temperature quality, and flicker-free dimming – faithfully recreating stage and studio scenarios.
The SHEHDS Mini LEKO 100W LED ellipsoidal spotlight is not a product that “looks great on paper.” It is a professional imaging light truly designed for small theatres, TV studios, exhibitions, and compact stages. What it delivers: precise light shaping, clean edges, true colors, and a quiet environment. What it offers: manual zoom, four-leaf framing shutters, high-CRI white light, flicker-free dimming, DMX control, and ultra-quiet operation. One small light can be truly professional.
